Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 223
Fig. 712.—Angle Postformed of Two Piecesbutting and boltedtogether. Fig. 715.—Method of connecting Window FramesFig. 714.—Method of fixing Door Frame in Half- in Half-timbered Work. timbered Work. (For Fig. 713, seepreuious page.) … ■ Fig. 716.—Front Portion of Half-timbered Cottage. HALF-TIMBER CONSTRUCTION. 201 painted, red-lead mixed with boiled oilbeing used for all joints. Various formsof half-timber work are shown in sectionby Figs. 708 to 713 (scale = 1 in. to1 ft.). In Fig. 708 the angle posts shownare 8 in. by 8 in.,…
Carpentry · Joinery
