Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 266
Fig. 814.—Enlarged Detail at G(Fig. 811) Fig. 813.—Showing Separate Pieces at the Head of Raker. Fig. 811.—Vertical Section throughFront Wall, showing System ofShoring (Fig. 810).11 … Fig. 815.—Enlarged Details of B,C, and D (Fig. 811). 242 CARPENTRY AND JOINERY. shore to pass through, and this shore wouldcarry the end of the needle. The outerdead shore l (Fig. 811) should be longenough to rest on a sill bedded firmly in thearea as shown. As a stay to these standards, angle of…
Carpentry · Joinery
