Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 335
ut the planof the drawers. The length is 2 ft. 4J in.between the standard and ends. Let thedrawers stand back 1 in. from the face edgeof the end to give room for the drop handle.On another rod (2) set out the vertical 308 CARPENTRY AND JOINERY. section, shown at Fig. 999. Divide up the door, the… … detail of the tray is shown at Fig. 998 ; adetail of the cornice at Fig. 1001 ; and theplinth at Fig. 1002. It will be noticed thatther bottom projects sufficiently from theface of the ends to take the thickness of the end e of a tray, dotted lines representing thedovetails. The top edge of the rim…
Carpentry · Joinery
