Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 366
HALF TIMBERED PORCH AND ENTRANCE DOORWAY DOORS AND DOOR FRAMES. 337 the case of commoner work, instead of pre-paring and fixing grounds, pieces of board,2 in. or 3 in. wide and 1 ft. or so long, arefixed at intervals of 12 in. or 15 in., as indi-cated at h and d (Fig. 1119). This exampleshows the… … Fig. 1123.—Taking Width of Door with TwoRods. of jamb linings are represented at Figs. 1121and 1122. The form at Fig. 1121 has asingle rebate made out of the solid, the jamband head being grooved and tongued to-j gether as shown. A rebate on each side isshown at Fig. 1122 ; thus a solid stop is…
Carpentry · Joinery
