tbe squared round to the inside edge, andwedging room allowed on the back. Mark ? CD rebate ; c equals the depth of the rebatefor bars—namely, in this case, T\ in. Insetting out the vertical marginal bars, fromthe back edge of the pattern stile set outone bar, then, placing it on the outside ofthe… … Fig. 1222.—Part Views of Lock Rail and Dimin-ished Stile of Door, indicating Method ofSetting Out. the g^-in. portion of the slip (Fig. 1221)inside the top edge of the lock rail and thebottom edge of the top rail, this being thedepth the ovolo mould works down, also thedepth of the rebate. From…
