Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 412
Fig. 1257. Fig. 1256.—Front Eleva-tion. Fig. 1257.—HalfHorizontal Sectionthrough Lower Panels,and Half HorizontalSection through CentrePanels on Lines A B andC D. Fig. 1258.—Ver-tical Section throughCentre of Fanlight andCentre of Panels. DOORS AND DOOR FRAMES. 383 … Fig. 1259.—Inside Elevation. as an attempt to save time here may leadto costly errors. The architects drawingsi should be carefully consulted, particularlythe enlarged details to half-inch or largerscale, together with full-size sections ofmouldings and panels, which are generallysupplied by…
Carpentry · Joinery
