Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 420
Fig. 1272.—Conventional View of Architrave andBase Block reversed at Fig. 1262. moulded, or beaded and ploughed fortongues (see Fig. 1254). Hardwood keys orwedges are prepared, and sometimes addi-tional gib pieces a (Fig. 1270) are alsoprovided ; cross tongues are glued into oneof the stiles ; then… … Fig. 1271.—Conventional Sectional View of Rail,Panels, etc., at A (Fig. 1259). wedges connecting the stiles finally driventight. After the glue is dry, the ends ofthese are cut out level with the bottom ofthe plough grooves. The panels can thenbe inserted and the door wedged up. Thebolection…
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
