Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 433
Fig. 1303. Fig. 1304. Fig. 1305. Fig. 1303.—Enlarged Section of Circle-on-Circle Swing Doors through Transom and Fanlight on Line A A (Fig. 1301). Fig. 1304.—Enlarged Section through Upper Part of Circle-on-Circle Swing Doors on Line B B (Fig. 1301). Fig. 1305.—Enlarged Section through Lower Part… … Fig. 1306.—Enlarged Section through Stiles of Circle-on-Circle Swing Doors on Line D D (Fig. 1301). DOORS AND DOOR FRAMES. be got out by the aid of lines, but where adefinite curve is required the former methodis more accurate and reliable. The materialwill be cut as shown by the dotted lines,d e f…
Carpentry · Joinery
