Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 459
Fig. 1398.—Joints between Barsof Solid Window. widest part; frieze rail of frame whichmeets bottom rail of sash, If in. by 1J in. … Fig. 1395.—Detail of Joints at Bottom of Framingsat Transom and Head. This is shown at Figs. 1392 and 1396.The under surface of the head of the frame,it will be noticed, is splayed a little. Thisis to allow the bead marked b, which hasto be nailed to the top rail of the sash, toclear the head of…
Carpentry · Joinery
