ulding Sash Bars onthe Sticking Board.—A short length ofa suitable form of sticking board for therebating and moulding of the bars is shownat Fig. 1490. It is made of a board 6 in.to 9 in. wide, and of any suitable length,the base being dovetail-keyed on the underside as indicated at d and e (Fig.… … At f is shown a piece of bar in position forthe first rebate. The strip c is ploughedso as exactly to fit the tongue of the barwhilst the sticking of the moulding is beingdone, as indicated at h and k. The rebateand plough grooves must vary according tothe size of the bars being worked ;…
