Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 593
Fig. 1800.—Setting Out Angles for Mitres. … Fig. 1801.—Setting Out Block for Obtuse Mitres. Mitre of Moulding on Oblique Corner. To draw the elevation and plan of amoulding mitre round an oblique angle of awall, and, inclined on both walls (Fig. 1802),draw a e, the elevation of the corner of thewall. From a draw a d at the slant of…
Carpentry · Joinery
