297. Fig. 298. Fig. 299. Fig. 297.—Screwed Joint Complete. Fig. 298.—Screwed Joint, before Sliding into Position. Fig. 299.—Edges of Boards to be Screw Jointed. to 300); the screw heads enter the holesbored for them, the edge is then slotted forabout | in. beyond the hole to allow thestem of the… … Jig. 306.—Pair of Single Tenons with Groovesand Slip Feathers. JOINTS. 67 Housing.—The simple housing joint isshown by Fig. 301. Tenon Joints (Joiners).—Some tenonjoints have already been shown under the | heading, Joints in Carpentry (p. 55).Further tenon joints, more especially usedin joinery,…
