Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 98
Tension Rod. eighth by being mortised and housed to Floors with Trussed Beams. receive the binders, various forms of stirrup In warehouses and factories where there irons have been introduced to carry the are heavy loads and vibration the girders FLOORS. 81 are sometimes strengthened by… … (see Fig. 317) for the insertion of the nails.A great advantage in this form of struttingis that, although the joists may shrink inthickness and depth, the strutting remainsfirm owing to the greatest shrinkage takingplace in depth. This will be made clear byFig. 359. Let a, b, c, d represent the…
Carpentry · Joinery
