A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class (1864)

Bourne, John · New York, D. Appleton & co. · leaf 54

An illustration from A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class, 1864, leaf 54
38 COEXISH BOILEKS. species of boiler jDrincipally used in Cornwall. In this boilera large internal cylinder or flue runs from end to end. In thefore part of this cylinder the furnace is placed, and behind thefurnace a large tube filled with water extends to the end of theboiler. This internal tube…

Steam engineering · Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
