A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class (1864)

Bourne, John · New York, D. Appleton & co. · leaf 85

An illustration from A catechism of the steam engine in its various applications to mines, mills, steam navigation, railways, and agriculture. With practical instructions for the manufacture and management of engines of every class, 1864, leaf 85
68 EXAMPLES OF MODERN LOCOMOTIVES. 132. Q.—What is the tender of a locomotive ? A.—It is a carriage attached to the locomotive, of which thepurpose is to contain coke for feeding the furnace, and waterfor replenishing the boiler. 133. Q.—Can you give examples of modern locomotives ?A.—The most… … construction. Fig. 30 represents Goochs express engine, adapted Fig. 81.

Steam engineering · Steam-engines
