58 EXAMPLE OF A SIDE LEYER ENGINE. from each end of the cross head to one of the side levers orbeams. A similar cross bar at the other end of the beamsserves to connect them together and to the connecting rodwhich, j)roceeding from thence upwards, engages the crank,and thereby tm-ns romid the… … ^-^^^ A.—Fig. 2G is a side elevation of a side lever engine; x xrepresent the beams or keelsons to which the engines are at-tached, and on which the boilers rest. The engines arc tied MODE OF STARTIJifG A MARINE ENGINE. 59 down by strong bolts passing througli tbe bottom of the vessel,but the…
