e less than 15 inchesthick on the face, and 4 feet long by not less than 2 feet G inches onthe bed, ami to be as well dressed as the hollow quoins. A groove for the caisson is to be formed across the bottom, and upthe side walls at each end of the lock as represented in the drawiug.On the outiside… … z.ar tremity of the lock, there is to be a pUitforra of well squared stone 2feet ti inches in depth, also the aforesaid grooves and the lockchambers with quoin stones 3 feet long by 2 feet in breadth. Twocourses of bond stone are to be built in tlie wing walls and counter-forts, 15 inches thick…
