The Civil engineer and architect's journal, scientific and railway gazette (1839)
London : [William Laxton] · leaf 414
ade every struta beauty, conducted the active force down those ribs as easily as wateris conducted down a pipe, and then, instead of leaving the active forcewithin each rib to expend itself in committing unknown and unre-strained damage to the walls of the fabric, he united their force in one[loint… … N, nave. A, A, aisles. R, R, &c., ribs of the vaulting, the several thrustsof which all uniting at the centre C ; the dynamic action is confined to onepoint lending to move from V to F. F, flying-buttress, falling against thepoint C, in the direction exactly suited for opposing the united…
Architecture · Civil engineering · Science
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
