Blves work, I I, Cross-bar, and K K, Eccentric rods, for working the slide valves. I,, Opening between slide valve casing and condenser. M M, Condensers. N N, Air-pumps, n n. Delivering valve openings. O, Crank for working air pumps. P P, Hot water cisterns. Q Q, Feed pumps. R R, Bllgs pnmps. The… … A, Air-pump.—B, Pflrt of condenser—C, Foot-valve.—D, Delivering valve.—E, Hotwater cistern-— F, Bracket for suppor.ing guide-rods for air-pump cross-bar. The following extract from the specification of a Patent, granted March22,1842, to Mr. Joseph Miller, will further explain the construction ofthe…
