The Clyde from its source to the sea, its development as a navigable river, the rise and progress of marine engineering and shipbuilding on its banks, and the leading historical, geological, and meteorological features of the Clyde Valley (1888)

Millar, W. J · London, Blackie · leaf 254

An illustration from The Clyde from its source to the sea, its development as a navigable river, the rise and progress of marine engineering and shipbuilding on its banks, and the leading historical, geological, and meteorological features of the Clyde Valley, 1888, leaf 254
whole cylinder full of steam would be used. If cutoff at say half-stroke, the mean pressure would now heapproximately seven-eighths of what it was in thefirst case. But only one-half of the steam is now used. THE RIVER. 227 It is, therefore, economical to use the expansive forceof the steam; and to… … Longitudinal Section of Marine Boiler. In the compound system, therefore, an advantageis gained; and in the triple and quadruple systemsa still further improvement arises from the use of steamat a higher pressure and expanded more fully, wherebyless steam can be made to give a better mean result.A…

Steam-navigation · Clyde River (Scotland)
