Complete perspective course : comprising the elementary and advanced stages of perspective, the projection of shadows and reflections, with exercises in theory and practice, also the practical application of perspective (1900)
Spanton, J. Humphrey (John Humphrey) · London : Macmillan and co. · leaf 221
will again be representedby lines converging to a vanishing point; the position of thispoint will be determined by the intersection with the pictureplane of the ray of light passing from the sun through thestation point, i.e. of a vanishing parallel of the suns rays [13]. 98. When the sun is in the… … Fig. 140 centre of the luminary, at right angles to tlie plane of projection,will meet it in a point called the seat of the luminary; e.g. let usassume the ground plane (Fig. 140) to be the plane of projection,and L the vanishing point of the suns rays. As a vanishingpoint represents a point at an…
Perspective
