, if wevisit the power-house, to be a ponderous affair, sugges-tive to the untechnical mind of impenetrable mysteries.Yet in reality it is a device essentially the same in con-struction as the motor which drives the train. Thatis to say, its unit of construction consists of a wire-wound armature… … Lower figure copyrighted by N. Y. Edison Co. AN ELECTRIC TRAIN AND THE DYNAMO THAT PROPELS IT. The lower figure gives an interior view of a power house of the ManhattanElevated Railway Company. The upper figure shows one of the electric enginesoperating on the New York Central Lines just outside of…
