Correlated courses in woodwork and mechanical drawing (1912)
Griffith, Ira Samuel, 1874-1924 · Peoria, Ill., The Manual arts press · leaf 93
tiser. Trimmer.It is possible so to arrange these machines that the circular-saw andplaner may be used in getting out stock for other classes. The floorplan given contemplates such use. EQUIPMENT FOR HIGH SCHOOL MECHANICAL DRAWING. A special room should be provided for the teaching of high… … Fig. 12. table for mechanical drawing. Tables have much to commend them over the pedestal. They areeasily swept around and keep a room looking orderly. Fig. 12 showsa type of table that is commendable. On the left are drawers forkeping the students instruments. On the right is a drawer for…
Woodwork (Manual training) · Mechanical drawing
