Cottage residences : or, A series of designs for rural cottages and cottage villas, and their gardens and grounds. Adapted to North America (1847)
Downing, A. J. (Andrew Jackson), 1815-1852 · New York : Wiley and Putnam · leaf 127
the plan of the second and basement stories so easily under-stood, that it will not require any further plans in illustration. Details. A portion of the porch inFig. 43, shows the manner of orna-menting this part of the building bybrackets. Four varieties of brackets,suitable for the roof supports… … mimmimm i!i!!!U.llrtU|[Fig. 42.] building; b, one of lesser size, pro-per for the projection of the gables ;c is another variation, employed in thebold projection of the gable in front,over the porch, and d, is a form em-ployed for eave brackets, when it isthought advisable to continue themalong…
Architecture, Domestic
