er Rolls.H. Lap Roll. J. Lap. K. Grid. M. M. Dust Flues. Breaker Suction fan A has its suction con- Lapper—Proces.s. nected with interior of perforatedscreens B B. Air is thus drawn frominlet fluejthrough the perforationsin screens. The inlet Hueleads from the delivery flue of the opener. Suction… … 14 Feed rolls C draw sheet of cotton in and feed it tobeater. Beater D, revolving about 1,400 revolutions per min-ute, beats cotton down over grids K. Fan E, connected like fan A, draws cotton againstscreens F F. Screens F F condense cotton like screens B B.Calender rolls G condense the sheet…
