Cotton mill processes and calculations. An elementary text book for the use of textile schools and for home study (1899)
Tompkins, Daniel Augustus, 1851-1914 · Charlotte, N.C., The author · leaf 42
cotton from cylin-der. Doffer comb F removes sheet from doffer. Sheet is drawn through trumpet G by calender rollsH. The sheet is thus formed into a round mass, calledsliver. Condenser rolls J take sliver and deliver it to coilerhead. Coiler is a revolving pbte with a hole in it, revolvingin such a… … Fio-. 6. Coils ill Can. 32 Fisf. 6 shows how coils are laid in can. More stockmay be put in a can in this way than any other. Fig. 7 shows how sliver is delivered from calenderrolls R on card, taken to condenser rolls P, ai.d dehveredthrough hole T in coiler head to can U. By following the gearing,…
Cotton growing · Cotton manufacture
