de is heated by steam or hot-water pipes and is forced up into the rooms above by more coldair from outside. Another method is illustrated inFig. 81; cold air from outside is ad-mitted beneath a radiator which isinclosed except at the top. The airenters as described above. Ventilating a soil pipe.… … Fig. 81. — Ventilating bymeans of a radiator. 114 PHYSICS OF THE HOUSEHOLD the bottom and top of this pipeto provide ventilation. Thearrangement of the soil pipe isshown in Fig. 82. It will benoticed that there is a fresh-airinlet near the bottom, and thatthe pipe extends through theroof and is…
