current comes out on one section, and duringthe other half on the other; but since the commutator revolveswith the armature, the current always comes out into the outercircuit from one brush and returns on the other. Thus thecurrent in the outer circuit always flows in the same direction,that is,… … GENERATOR Fig. 163.- MOTOR - The dynamo or generator and the motor. power dynamos by means of wires, Fig. 163. Then turn thearmature of the first dynamo by hand power and the currentproduced makes the armature of the second dynamo revolve.That is, the second dynamo acts as a motor. Now turn…
