cylinders of the same diameter.The very small circles show the positions of the equivalent linecharges. Simiarly Fig. 121 shows accurately the trend of thelines of force between two parallel metal cylinders one of whichsurrounds but is not co-axial with the other; the small circles IDEA OF… … Fig. 121. method of electrical images. The origin of this term may be illus-trated by discussing Fig. 122. A line charge A near and parallelto a metal cylinder BB having an equal and opposite amount of
