Advanced theory of electricity and magnetism; A text-book for colleges and technical schools (1915)
Franklin, William S. (William Suddards), 1863-1930, MacNutt, Barry, 1878-1936. joint author · New York, Macmillan · leaf 245
ans) per second in a counter-clock-wise direction as seen from the end B; and the projections of theattached arrows upon the plane of the paper represent the instan-taneous values at the various points of the transmission line ofthe alternating current i which is associated with a simple wavetrain… … side view of clock-diagram model end view of model Fig. 169.Clock diagram model of a simple wave train moving to the right. line from left to right. In a moving wave train, current i andvoltage e are in phase with each other everywhere, so that theprojections of the radial arrows in Fig. 169…
