l mounted on a singletube controls the aileron and elevator movements, whilst therudder is actuated by a pivoted foot-lever. A complete set of 42 THE AEROPLANE. instruments is mounted on the instrument board in front ofthe pilot, and a wireless set driven by a motor-cycle engine ismounted in front… … Fig. 19.—Sopwith 100 H.P. tractor hj-dro-aeroplane. inspection door. The doors are screwed down on rubberseatings with butterfly nuts, thus ensuring a watertight joint.A 100 H.P. Anzani engine is mounted on this machine. 80 H.P. AvRO Biplane (see fig. 20). The main planes are staggered, giving the…
