Higbee, F. G · New York, John Wiley & Sons · leaf 191
Fig. 144. — Illustration showing two methods of making joints in paper modelmaking. The method at the right gives better results for joints along straightlines while the one at the left is better for curved joints. … Fig. 144A. — Patterns for the parts of the model shown in Fig. 147 before beingglued together. Note the method for making the joints. . MODEL MAKING l8l Two convenient methods for making the joint along an elementof the surface are shown in Fig. 144. The joint in the cyHnderon the right is…
Geometry, Descriptive
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
