Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 324
luminum Cylinder and Crank-Case Castings are Used. Crank-Case Construction 323 in the fuselage are substantial-ribbed members cast inte-grally with the upper half. The approved method of crank-case construction fa-vored by the majority of engineers is shown at the top ofFig. 141, bottom1 side up.… … Fig. 143.—Simple and Compact Crank-Case, Possible When Radial CylinderEngine Design is Followed. of separately cast caps retained by suitable bolts. Inthe construction outlined the bottom part of the caseserves merely as an oil container and a protection forthe interior mechanism of the motor. The…
Airplanes
