Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)

Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 410

An illustration from Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes, 1917, leaf 410
special spanners; P, socket wrenches,long handle; Q, long handle, stiff bristle brushes forcleaning motor; E, gasoline blow torch; S, hand drill;T, spools of safety wire; U, flash lamp; V, special pullerand castle wrenches; W, oil can; X, large adjustablemonkey wrench; Y, washer and gasket cutter;… … 409 410 Aviation Engines

Airplanes

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
