Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)

Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 462

An illustration from Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes, 1917, leaf 462
Fig. 190a.—Illustrations Depicting Wrong and Right Methods of Swing-ing the Stick to Start Airplane Engine. At Top, Poor Position toGet Full Throw and Get Out of the Way. Below, Correct Positionto Get Quick Turn Over of Crankshaft and Spring Away fromPropeller. 461 462 Aviation Engines that a…

Airplanes

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
