Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)

Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 569

An illustration from Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes, 1917, leaf 569
of Christensen Air Starting System Shown at A, andApplication of Piping and Check Valves to Cylinders of Thomas-Morse Aeromotor Outlined at B. gasoline is injected in with the air so an inflammable mix-ture is present in the cylinders instead of air only. Thisignites easily and the engine starts…

Airplanes

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
