Elements of graphic dynamics; an elementary textbook for students of mechanics and engineering (1919)
Andrews, Ewart S. (Ewart Sigmund) · London, Chapman and Hall, Ltd. · leaf 76
Fig. 33.—Application to Zeuners Valve Diagram. the valve at its centre, the ^ Q 0 J gives the correspondingcrank angle, so that for the crank angle a the movementof the valve from its central position is 0 R. The arrange-ment of the simple sUde valve is shown diagrammaticaUyin Fig. 34. The slide…
Mechanics, Applied · Dynamics · Graphic methods
