esvltant of those forces acting at 404 MECHANICS OF ENGINEERlNa the vertices intervening between the given segments. Here,the resultant of Pi P2 A acts through d. 329. Vertical Reaction of Piers, etc.—Fig. 354. Given thevertical forces or loads P, P^ and P^ acting on a rigid body(beam, or truss)… … FiQ. 354. equil. with P, P.^ and P3. The introduction of the equaland opposite forces P and P in the same line will not dis-turb the equilibrium. Taking the seven forces in theorder P V^ Pi P^ P3 V„ and P, a force polygon formed withthem will close (see (h) in Fig. where the forces whichreally lie…
