The San Francisco earthquake and fire; a brief history of the disaster; a presentation of facts and resulting phenomena, with special reference to the efficiency of building materials, lessons of the disaster (1906)

Himmelwright, Abraham Lincoln Artman, 1865-, Roebling Construction Co · New York, N.Y., The Roebling construction company · leaf 40

An illustration from The San Francisco earthquake and fire; a brief history of the disaster; a presentation of facts and resulting phenomena, with special reference to the efficiency of building materials, lessons of the disaster, 1906, leaf 40
HOBART BUILDIN(i. Fovirth Story. Showing the failure of the hollow tile 3 and 4 partitions, and of thehollow tile protection around the vaults. The column protection was of two-inch hollow tile blocks. The workmanship andmaterial being of a better grade than that of the partitions, in many cases… … HOBART BUIIiDING. Fourtli Floor. Showing the tops of tlu- deflected and warj)ed floor beams, which projectedabove the segmental brick arches. The regular concrete filling between the floor arches and the wood floor finish wasomitted. The burning of the wood floor heated the.se unprotected beams…

Building, Fireproof · Earthquakes · Fires
