A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 114

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 114
ing and planking(including calking seams), and forecastle deckbeams; also for faying knees, rounding edging ofwaterways, main rails, pin rails, etc. In Figure 61 is shown a timber starting throughthe machine at an angle of 11 degrees to the right,and in Figure 62 the other end is shown comingout of… … 112 COUESE IN WOODEN BOAT AND SHIP BUILDING
