A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 115

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 115
112 COUESE IN WOODEN BOAT AND SHIP BUILDING … MACHINES AND LABOR-SAVING DEVICES 113 In beveling ceiling planking, a complete strakecan be laid out at a time; battens are nailed on eachtimber, and the timbers placed on roller skidsalongside of the machine, from which they canquickly and easily be placed on the carriage andrun through. The…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
