A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 148

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 148
d. The timbers are cut to the required shape beforesteaming them. All joined surfaces throughoutthe construction of the hull should be treated witha wood preservative before installing. Clamps and Wedges.—When ready to install,one end is fastened and held in position by a clamp,and as the plank is… … 146 COURSE IN WOODEN UOAT AND SHIP BUILDING bring the planking up tight against the frames.These hold it in position until fastened, when thewedges are removed. The garboard strake is fastened to each frame

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
