A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 153

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 153
Figure 94.—Ready to Launch. The wedges are placed across the grain of thewood through which they are driven. The holesfor the treenails are bored with long, power, shipauger bits. The head of each treenail is protected with an 150 COURSE IN WOODEN DOAT AND SHIP BUILDING … Fij;:nre DT).—Framing the Ioop Deck.

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
