A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 161

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 161
h cargo booms. Fignire 98 shows the shapingof the masts. These masts were completely shapedby hand, the rough cuts being made with an adzeand finished with a hand plane. Shipyards and Ways.—Figures 99 and 100 give apanoramic view, taken June 12, 1918, of a prom-inent shipyard on the Atlantic Coast.… … Figure 104.—Boat Deck, Standard Wood Steamship. PLANKING AND FINISHING IS*

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
