A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 163

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 163
Figure 106.—Poop Dofk. 160 COURSE IN WOODEN BOAT AND SHIP BUILDING … Figure 107.—Bridge Decli, Standard Wood Steamsliip, PLANKING AND FINISHING 161 This makes a total capacity for ten ships. In thedistance is seen the fitting-up wharf, showing aship with the painted camouflage effect, or protec-tive coloring adopted for use in wartime. STANDAED WOOD STEAMSHIP Plans…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
