A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)
Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 164
Figure 107.—Bridge Decli, Standard Wood Steamsliip, PLANKING AND FINISHING 161 This makes a total capacity for ten ships. In thedistance is seen the fitting-up wharf, showing aship with the painted camouflage effect, or protec-tive coloring adopted for use in wartime. STANDAED WOOD STEAMSHIP Plans… … Figure 108.—Forecastle Deck. Emergency Fleet Corporation, are shown in Fig-ures 101 to 111 inclusive. An inboard profile ofthe ship is seen in Figure 101, and the arrange-ment of the decks and numerous other detailsappear in the remaining illustrations. Figure102 shows details of the wheel house…
Shipbuilding
