e 13.—Detail of Rabbet. (Section Through A-A, Figure 12.) formed by the intersection of the bearding, rabbet,and first water lines. Make a template or mould the thickness of theplanking, as shown at G, about l^o wide and 3long, depending upon the size of the rabbet to becut. Bevel one end as shown,… … STEM AND STERN CONSTRUCTION 39
