Figure IS.—Picking Up Lines from Mould Loft Floor with a FlexibleSteel Template. Cut the moulds full of the line to allow for fair-ing up, finishing the mould by hand. Each mouldis numbered so it can readily be placed in its properlocation. FUTTOCKS AND FRAMES 45 i … 4e COURSE IN WOODEN BOAT AND SHIP BUILDING The sheer, diagonal, and keel lines are trans-ferred from the floor to the moulds. These lineswill be needed in lining up and setting the frames^and for locating the beveling spots and running-the ribbands. Surmarks.—The marks on the moulds showing
