A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 62

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 62
Figure 27.—Sawing Timbers. FUTTOCKS AND FRAMES 39 … 60 COURSE IN WOODEN EOAT AND SHIP BUILDING plank which have the breadth of the boat at par-ticular stations marked on them, and unite theheads of the futtocks to the required width. Thesepreserve the form of the boat while it remains inframe and until the beams are crossed. NoteFigures 28 and 30.…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
