A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 65

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 65
FUTTOCKS AND FRAMES 63 each other, but the connection is more usually keptup by one length of the ribband made to overrunthe other. FAIRING XJP A great deal depends upon the mechanical eyeof the builder in fairing up, as a good design caneasily be ruined at this stage of the construction.The lines…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
